HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface

HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface
HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface

Large Image :  HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 100-330
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day

HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface

Description
Material: High-density Polyethylene (HDPE) Type: 100-330
Color: Black Welding Space: 330mm
Thickness: 1mm Height: 100
Surface: Textured & Perforated Standard: ASTM
High Light:

Gravel Stabilizer cellweb system

,

100mm cellweb system

,

Gravel Stabilizer cellweb 100mm



PRODUCT DESCRIPTION

HDPE Gravel Stabilizer Geocell With Strong Load Support



Product Introduction



Cellular Confinement Systems have been used to improve the performance of both paved and unpaved roads by reinforcing the soil in the subgrade-base interface or within the base course. The effective load distribution of geocell creates a strong,stiff 3D cellular mattress which can reduce vertical differential settlement into soft subgrades, improves shear strength, and enhances load-bearing capacity, while reducing the amount of aggregate material required to extend the service life of roads.


Specifications



Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18





 Application



HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 0

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 1

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 2

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 3

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.



HCNS Manufacture                                                                                                                                  HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 4                                                                                     HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 5



Our Certificates and HDPE Geocell Testing reports

HDPE Gravel Stabilizer Cellweb System 100mm For Reinforcing Subgrade Base Interface 6
