Product Details:
|
| Material: | PP PET HDPE | Project Solution Capability: | Graphic Design, 3D Model Design, Others |
|---|---|---|---|
| Application:: | Basement, Road Construction .mine Laneway | Design Style: | Traditional |
| Product Name:: | PP Biaxial Geogrid | Color: | Black |
| Origin: | Anhui, China | Tensile Strength: | 15kn 20kn 25kn 30kn |
| High Light: | 15kn Soil Reinforcement Geogrid,20kn Soil Reinforcement Geogrid,20kn polyester geogrid |
||
PRODUCT DESCRIPTION
PP/PE/HDPE Uniaxial Geogrid For Retaining Walls And Bridge Abutment
Product Introduction
Uniaxial geogrid is made from high polymer, extruded and pressed into sheets and made into regular net, and then stretched vertically. It can improve stability and bearing capacity. It features preventing roadbed from deformation and crack due to roadbed material wash off and retaining wall bearing capacity improvement.
Specifications
| Uniaxial Geogrid(HDPE) | ||||||
| Properties | Test Method | Units | MD Values | |||
| GG60 | GG80 | GG120 | GG160 | |||
| Polymer | - | - | HDPE | HDPE | HDPE | HDPE |
| Minimum Carbon Black | ASTMD 4218 | % | 2 | 2 | 2 | 2 |
| Tensile Strength @2% Strain | ASTMD 6637 | KN/m | 16 | 23 | 35 | 47 |
| Tensile Strength @5% Strain | ASTMD 6637 | KN/m | 31 | 44 | 65 | 85 |
| Tensile Strength | ASTMD 6637 | KN/m | 60 | 80 | 120 | 160 |
| Strain @ Ultimate Strength | ASTMD6637 | % | 10 | 10 | 10 | 10 |
| UV Resistance | ASTMD 4355 | % | 98 | 98 | 98 | 98 |
| Oxidation Resistance | EN ISO 13438 | % | 100 | 100 | 100 | 100 |
| Brittleness | WASHDOT T926 | - | Pass | Pass | Pass | Pass |
| Roll Width | m | 1 | 1 | 1 | 1 | |
| Roll Length | m | 75 | 50 | 30 | 30 | |
| Roll Weight | kg | 34 | 30 | 26 | 33 | |
