HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm

HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm
HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm

Large Image :  HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 100-445
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 7-20 days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day

HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm

Description
Material: HDPE Type: 100-445
Color: Black Welding Space: 445mm
Thickness: 1.5mm Height: 100
Surface: Perforated Standard: ASTM
High Light:

Honeycomb driveway stabilizer

,

445mm driveway stabilizer

,

445mm honeycomb stabilizer for pea gravel



PRODUCT DESCRIPTION

HDPE Plastic Soil Gravel Stabilizer 3D Geocell For Road And Slop Greening



Product Introduction

FEATURES:

1. flexible to fold during transportation, stretching out

2. filled with stone or concrete during service, forming into structure with powerful lateral confinement and rigidity.

3. used as cushion coat to strengthen loading capacity of weak ground or slope protection structure


FUNCTIONS:

1. Fix railway ground.

2.Fix weak ground of roads and increase loading capacicity.

4.used to build the support block struction

5.Act as independent wall, dock and break-water.

6.Treat desert, beach, riverbed and bank.







Specifications



Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18









Application



HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 0

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 1

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 2

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 3

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

                                                                                                      HCNS Manufacture

HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 4

Exhibition                                                                   HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 5

Our Certificates and HDPE Geocell Testing reports

HDPE Plastic Honeycomb Driveway Stabilizer For Pea Gravel 445mm 6
