Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell
Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell
Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell

Large Image :  Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 1.5-100-356
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union
Supply Ability: 35000㎡ per day
Contact Now

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell

Description
Raw Material: HDPE Plastic GeoMax Standard: ASTM
Cell Height: 50mm-300mm Geomax Model: GM356
Color: Black, Green, Brown, Black Yellow White Green, Green Or As Per Request Welding Space: 356mm
Cell Thickness: 1.5mm Geocell Surface: Textured&Perforated
Highlight:

Hdpe Geocell Gravel Stabilizer Grid

,

Hdpe Geocell Gravel Stabilizer

,

Driveway Geocell Gravel Stabilizer Grid

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell





Product Introduction

GeoMax® Hdpe Geocell can be used on slopes up to 1:1 to resist the erosive effects of wind and water run off by confining infill within it’s honeycomb-like structure. Made from a permeable geotextile Terram Geocell allows the free flow of water between cells which encourages drainage and vegetation establishment. The panels (supplied flat packed) are flexible enough to be formed around trees and other obstacles.

Specifications

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18









APPLICATION

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 0

SOIL REINFORCEMETN

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 1

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 2

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 3

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.



PRODUCTION LINE

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 4



INVENTION AND TESTING

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 5



PRODUCT AREA

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 6



CERTIFICATES

Driveway Geocell Gravel Stabilizer Grid Hdpe Geocell 7
