HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway
HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway
HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway

Large Image :  HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: GeoMax
Certification: CE
Model Number: GM100-356
Payment & Shipping Terms:
Minimum Order Quantity: 2500 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 3000㎡ per day
Contact Now

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway

Description
HDPE Geocell Material: 100% HDPE Plastic Geocell Standard: ASTM/GB
Height: 100mm Model: 100-330
Geocell Color: Black Welding Space: 330mm
Geocell Thickness: 1.5mm Surface: Smooth Or Textured Perforated
Density: 0.935-0.965 G/cm3
Highlight:

Plastic Geocell HDPE Ground Grid

,

100mm Height HDPE Ground Grid

,

ASTM Standard HDPE Ground Grid

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 0



HDPE Geocell Product Introduction

GeoMax® has over 20 years of experience manufacturing cellular confinement systems and has developed a market-leading multifunctional product and hold more than 100 invention patents.

We produce the GeoMax® system in following ISO and CE quality standards to guarantee that our clients always receive the best possible quality.
The system's performance of the system depends heavily on both maximal seam strength and consistent weld strength. Advanced machines and rigorous production processes enable us to provide customers with high caliber.

• ISO 9001:2016 International/Standards

• CE marking determined by adherence to harmonized EU standards



Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18

















































DETAILED PHOTOS



HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 1 HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 2

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 3 HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 4

APPLICATIONS

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 5

SOIL REINFORCEMENT

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 6

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 7

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 8

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.



PRODUCTION LINE

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 9



INVENTION AND TESTING

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 10



PRODUCT AREA

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 11



CERTIFICATES

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 12

PHOTO OF THE EXHIBITION

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 13



FAQ:



Q: What is Geocell made out of ?
A: Our honeycomb geocell structures are made out of a thick high-density polyethylene (HDPE) that's as strong as concrete. Engineers ultrasonically welded Geocell at certain intervals for maximum strength. Also, the product has perforation (holes) that provide natural drainage in your commercial project.

Q: What if my project dimensions are different than the Geocell panels ?
A: We can custom-design Geocell foundation grids to meet whatever project demands you have. Drainage pipes, trees, and other obstacles are not an issue when laying a solid geocell base. You can fit flexible Geocell panels around these objects that you can't do with concrete and steel.



Q: What GeoMax Geocell product testing has been done? Can I see the product specs?
A: Our support team would be glad to speak with you about product testing and specs. We consult your project through a free commercial evaluation to learn your specific needs. Schedule one now and we can get back to you in a few hours.

Q: Where is it manufactured ?
A: GeoMax geocell is manufactured in Anhui China.

Q: Can you do customize size ?
A: Yes, we can do customized strictly as your requirement.

Q: What Standard can you do?
A: We can do ASTM Standard and GB Standard, we can do customize standard as well.

HDPE Ground Grid Gravel Geocell ASTM Standard Channel Protection 100mm Height Plastic Geocell Driveway 14
