Product Details:
|
| HDPE Geocell Material: | 100% HDPE Plastic | Geocell Standard: | ASTM;GB |
|---|---|---|---|
| Geocell Height: | 250mm | GeoMax Model: | 250-660 |
| Color: | Black;Green;Yellow | Geocell Welding Space: | 660mm |
| Thickness: | 1.5mm | Geocell Surface: | Smooth;Textured;Perforated |
| HDPE GeocellDensity: | 0.935-0.965 G/cm3 | ||
| Highlight: | High Strength Geocell,Eco Friendly Geocell,Soil Stabilization Geocell |
||
HDPE Geocell Product Introduction
With more than two decades of expertise in crafting cellular confinement systems, GeoMax® has pioneered a multifunctional, industry-leading solution supported by over 100 patented innovations.
Our GeoMax® system is manufactured in strict compliance with ISO and CE quality standards, ensuring clients receive products of the highest quality. The system's reliability hinges on its exceptional seam strength and uniform weld integrity. Utilizing cutting-edge technology and meticulous production methods, we consistently deliver premium-grade solutions to meet customer needs.
• Certified to ISO 9001:2016 International Standards
• CE marked, demonstrating conformity with EU harmonized standards
Specifications
| Index Properties | Test Method | Units | Values | |||||||
| Material | - | - | 100% Virgin HDPE | |||||||
| Carbon Black content | ASTM D 1603 | % | ≥1.5 | |||||||
| Density | ASTM D 1603 | g/cm3 | 0.935-0.965 | |||||||
| Sheet Thickness ± 3% | ASTM D 5199 | mm | 1.5 | |||||||
| Seam Peel Strength | USACE GL-86-19 | KN/m | ≥14.2 | |||||||
| Tensile strength at Yield | ASTM D 1603 | KN/m | ≥22 | |||||||
| Environmental stress crack resistance | ASTM D 1603 | hrs | ≥5000 | |||||||
| OIT oxidation induction time | ASTM D 1603 | min | ≥150 | |||||||
| Type | GM330 | GM356 | GM400 | GM432 | GM445 | GM500 | GM660 | GM712 | ||
| Welding Distance(mm) ± 3% | 330 | 356 | 400 | 432 | 445 | 500 | 660 | 712 | ||
| Cell Depth(mm) ± 3% | 50,75,100,150,200,250 | |||||||||
| Dimensions | ||||||||||
| Expanded Cell Size (width×length) (mm) ± 3% | 250 x 210 | 260 x 225 | 290 x 260 | 320 x 275 | 315 x 300 | 360 x 300 | 470 x 450 | 510 x 475 | ||
| Expanded Cell numbers(width×length) | 10 x 34 | 9 x 34 | 8 x 34 | 8 x 34 | 8 x 34 | 7 x 34 | 5 x 34 | 5 x 34 | ||
| Expanded Section size (width×length) (m) ± 3% | 2.50 x 7.14 | 2.34 x 7.65 | 2.32 x 8.84 | 2.56 x 9.35 | 2.52 x 10.2 | 2.52 x 11.22 | 2.35 x 15.3 | 2.55 x 16.15 | ||
| Expanded Section Area (m2) ± 5% | 17.85 | 17.9 | 20.5 | 23.94 | 25.7 | 28.74 | 35.95 | 41.18 | ||
DETAILED PHOTOS
|
SOIL REINFORCEMENTGeomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement. |
|
SLOPE PROTECTIONGeomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection. |
|
CHANNEL PROTECTIONGeomax®(Hdpe Geocell) delivers stability and protection of channels |
|
RETAINING WALLSGeomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff. |
PRODUCTION LINE
INVENTION AND TESTING
PRODUCT AREA
FAQ:
Q: What is Geocell made out of ?
A: Our honeycomb geocell structures are made out of a thick high-density polyethylene (HDPE) that's as strong as concrete. Engineers ultrasonically welded Geocell at certain intervals for maximum strength. Also, the product has perforation (holes) that provide natural drainage in your commercial project.
Q: What if my project dimensions are different than the Geocell panels ?
A: We can custom-design Geocell foundation grids to meet whatever project demands you have. Drainage pipes, trees, and other obstacles are not an issue when laying a solid geocell base. You can fit flexible Geocell panels around these objects that you can't do with concrete and steel.
Q: What GeoMax Geocell product testing has been done? Can I see the product specs?
A: Our support team would be glad to speak with you about product testing and specs. We consult your project through a free commercial evaluation to learn your specific needs. Schedule one now and we can get back to you in a few hours.
Q: Where is it manufactured ?
A: GeoMax geocell is manufactured in Anhui China.
Q: Can you do customize size ?
A: Yes, we can do customized strictly as your requirement.
Q: What Standard can you do?
A: We can do ASTM Standard and GB Standard, we can do customize standard as well.
