250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance
250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance
250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance

Large Image :  250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: GeoMax
Certification: CE,ISO9001-2015
Model Number: GM250-356
Payment & Shipping Terms:
Minimum Order Quantity: 3000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 3000㎡ per day
Contact Now

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance

Description
Material: 100% HDPE Plastic Thickness: 1.2-1.5mm
Surface: Smooth Or Textured Surface Tensile Strength: 25kN/m
Standard: ASTM; GB Standard； Peel Strength: 14.2 KN/m
Height: 250mm Color: Black;Yellow;Green
Welding Distance: 356mm Density: 0.950 G/cm3
Certificate: CE;ISO;ASTM
Highlight:

heavy-duty HDPE geocell grid

,

250mm depth geocell for slope stabilization

,

HDPE geocell for erosion resistance

HDPE Geocell GM356-250mm Geocell for 2:1 Slopes, Vegetation and Soil Retention

GEOMAX® GEOCELL PRODUCT INTRODUCTION

Manufactured from high-density polyethylene, GeoMax® Geocell forms a deep cellular framework that confines soil and aggregate infill. This confinement improves slope integrity by distributing loads evenly and reducing erosion caused by rainfall or surface runoff.
The system is widely applied in slope protection projects where conventional retaining methods are difficult to construct.

SPECIFICATIONS


Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18

















































DETAILED PHOTOS

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 0 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 1

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 2 250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 3

APPLICATIONS

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 4

SOIL REINFORCEMENT

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 5

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 6

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 7

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

PRODUCTION LINE

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 8

INVENTION AND TESTING

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 9



PRODUCT AREA

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 10

FAQ:

Q1: Why is a 250 mm cell depth recommended for steep slopes?
Deeper cells provide stronger confinement, improving resistance to soil displacement and erosion.

Q2: Can locally available soil be used as infill?
Yes. Local soil can be used if it meets basic gradation and compaction requirements.

Q3: How does the system handle heavy rainfall conditions?
The cellular structure slows runoff velocity and improves drainage, reducing erosion.

Q4: Is the geocell system compatible with drainage layers?
Yes. It is often installed over geotextiles or drainage layers for enhanced performance.

Q5: Can this system be used on curved or irregular slopes?
Yes. The flexible structure adapts well to complex slope geometries.

250mm Depth Heavy-Duty HDPE Geocell Grid for Steep Slope Stabilization and Erosion Resistance 11
