Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement
Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Large Image :  Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 100-712
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement

Description
Material: HDPE Type: 150-445
Color: Black Welding Space: 445mm
Thickness: 1.5mm Height: 150
Surface: Textured Standard: ASTM
High Light:

Geocell For Road Construction

,

Black Geocell For Road Construction

,

HDPE geocell gravel driveway



PRODUCT DESCRIPTION



Erosion Control Black HDPE Geocells Ground Grid Paver Soil Reinforcement Slope Protection



Product Introduction



Geocell is a new type of high-strength geosynthetics, which is popular in domestic and abroad. It is a kind of three-dimensional network structure shaped by high-strength HDPE sheets through ultrasonic welding of high strength. Currently, it is being widely used in construction, such as highway, railway, bridge, dyke, etc.



Specifications



Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18









Application



Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 0

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 1

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 2

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 3

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

                                                                                                      HCNS Manufacture

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 4

Exhibition                                                                   Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 5

Our Certificates and HDPE Geocell Testing reports

Gravel Driveway Black HDPE Geocell For Road Construction Soil Reinforcement 6
