50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction

50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction
50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction 50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction

Large Image :  50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: Integral Insert Joint Geocell
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: as requested
Delivery Time: 7-15days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day
Contact Now

50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction

Description
Material: PP/PET Standard Color: Black
Height: 50-200mm Space: 500-800mm
Section Size: 12.5*4m Certificate: CE/ISO9001
Highlight:

customized textured geocell 200mm

,

customized textured geocell 50mm

,

Customized geocell products



PRODUCT DESCRIPTION

PP PET Integral Insert Joint Geocell For Road Construction



Product Introduction

The Integral Insert Joint Geocell is based on the manufacturing process of high-strength geocell. And it is produced by special processing methods to meet the requirements of different projects for the unity of the tensile strength of the cells and the overall strength of the cells. The jointing of the sheet is connected by a kind of U-shaped plug, so as to solve the problem that the strength of the cell sheet and the jointing are greatly different.



Specifications

PP  High Strength Riveted Geocell



Model Height(mm)

Space

(mm)

 Section size(m)

Sheet Longitudinal tensile strength

(≥Mpa)

Sheet horizontal tensile strength

(≥kn/m)

 Elongation ≤%

Jointing tensile strength

(≥kn/m)
TGGS50 50 500-800 12.5*4 120 / 15 120
TGGS75 75 500-800 12.5*4 120 / 15 120
TGGS100 100 500-800 12.5*4 120 / 15 120
TGGS150 150 500-800 12.5*4 120 / 15 100
TGGS200 200 500-800 12.5*4 120 / 15 100



PET  High Strength Riveted Geocell

Model Height(mm)

Space

(mm)

 Section size(m)

Sheet Longitudinal tensile strength

(≥Mpa)

Sheet horizontal tensile strength

(≥kn/m)

 Elongation ≤%

Jointing tensile strength

(≥kn/m)
TGGS50 50 500-800 12.5*4 130 15 10 130
TGGS75 75 500-800 12.5*4 130 15 10 130
TGGS100 100 500-800 12.5*4 130 15 10 130
TGGS150 150 500-800 12.5*4 130

15

 10 110
TGGS200 200 500-800 12.5*4 130 15 10 110

HCNS Manufacture                                                                                                                                  50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction 0                                                                                     50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction 1



Our Certificates and HDPE Geocell Testing reports

50-200mm PP PET Integral Insert Joint Customized Textured Geocell Products For Road Construction 2



Tag:

customized textured geocell,

envirogrid geocell,

geocell products
