Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization

Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization
Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization

Large Image :  Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 100-356
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day
Contact Now

Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization

Description
Material: HDPE Type: 100-356
Color: Black Welding Space: 356mm
Thickness: 1.5mm Height: 100
Surface: Perforated Standard: ASTM
Highlight:

stretched perforated Slope Protection Geocell

,

Slope Protection Geocell Mesh

,

stretched perforated geocell Mesh



PRODUCT DESCRIPTION

Textured HDPE Geocell For Slop Protection Retaining Wall And Soil Stabilization



Product Introduction

The geocell is a kind of 3d mesh cell structure formed by high strength welding of reinforced HDPE sheet material.
Generally by ultrasonic needle welding.Due to engineering needs, some holes in the diaphragm.

The geocell is a mesh cell structure formed by high strength HDPE or PP copolymer broadband, after strong welding or riveting
It retractable, transport can be folded up, when the use of the expansion and filling of soil and stone or concrete, with a strong lateral constraints and stiffness of the structure

It can be used as a cushion to increase the bearing capacity of soft foundation, or laid on the slope to form a slope protection structure, but also can be used to build retaining structure.







Specifications



Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18









Application



Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 0

SOIL REINFORCEMETN

Geomax®(Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 1

SLOPE PROTECTION

Geomax®(Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 2

CHANNEL PROTECTION

Geomax®(Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 3

RETAINING WALLS

Geomax®(Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.

                                                                                                      HCNS Manufacture

Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 4

Exhibition                                                                   Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 5

Our Certificates and HDPE Geocell Testing reports

Stretched Perforated HDPE Slope Protection Geocell Mesh For Retaining Wall And Soil Stabilization 6
