ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm
ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm
ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm

Large Image :  ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm

Product Details:
Place of Origin: ANHUI CHINA
Brand Name: Geomax
Certification: CE
Model Number: 1.5-100-445
Payment & Shipping Terms:
Minimum Order Quantity: 1000 ㎡
Price: Negotiation
Packaging Details: Folded strips are wrapped by film and layed on pallets or as requested
Delivery Time: 10-20 days
Payment Terms: T/T, L/C
Supply Ability: 2000㎡ per day

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm

Description
Raw Material: HDPE Plastic Geocell Standard: ASTM
Cell Height: 50mm-300mm Geocell Model: GM-445
Geocell Color: Black, Green, Brown, Black Yellow White Green, Green Or As Per Request Welding Space: 445mm
Cell Thickness: 1.5mm Geocell Surface: Textured&Perforated&smooth
Highlight:

ASTM Standard HDPE Geocells

,

Perforated HDPE Geocells

,

Slope HDPE Geocells

ASTM Standard Textured/Perforated HDPE Geocells For Slope/Retaining Wall/Road Reinforcement 100-445mm





Product Introduction

Hdpe geocells have the characteristics of light weight, flexible expansion, and small transportation volume, which can save us a lot of transportation costs. When we purchase something, due to its large size and long transportation distance, the actual product does not often occur because shipping costs are expensive. Buying a geocell can completely ignore the issue of large freight, which is definitely worth it.

Hdpe geocells are made of materials that are wear-resistant, chemically stable, and resistant to aging, acid, and alkali. Therefore, they can be used in any harsh environment and are widely used in deserts and other environments.

You can also freely change the distance between the height and geometric shape of the geocell according to the needs of the project. Many projects use it.



Specifications

Index Properties Test Method Units Values
Material - - 100% Virgin HDPE
Carbon Black content ASTM D 1603 % ≥1.5
Density ASTM D 1603 g/cm3 0.935-0.965
Sheet Thickness ± 3% ASTM D 5199 mm 1.5
Seam Peel Strength USACE GL-86-19 KN/m ≥14.2
Tensile strength at Yield ASTM D 1603 KN/m ≥22
Environmental stress crack resistance ASTM D 1603 hrs ≥5000
OIT oxidation induction time ASTM D 1603 min ≥150

Type GM330 GM356 GM400 GM432 GM445 GM500 GM660 GM712
Welding Distance(mm) ± 3% 330 356 400 432 445 500 660 712
Cell Depth(mm) ± 3% 50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3% 250 x 210 260 x 225 290 x 260 320 x 275 315 x 300 360 x 300 470 x 450 510 x 475
Expanded Cell numbers(width×length) 10 x 34 9 x 34 8 x 34 8 x 34 8 x 34 7 x 34 5 x 34 5 x 34
Expanded Section size (width×length) (m) ± 3% 2.50 x 7.14 2.34 x 7.65 2.32 x 8.84 2.56 x 9.35 2.52 x 10.2 2.52 x 11.22 2.35 x 15.3 2.55 x 16.15
Expanded Section Area (m2) ± 5% 17.85 17.9 20.5 23.94 25.7 28.74 35.95 41.18









APPLICATION

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 0

SOIL REINFORCEMETN

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.



ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 1

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.





ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 2

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.





ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 3

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.



PRODUCTION LINE

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 4



INVENTION AND TESTING

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 5



PRODUCT AREA

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 6



CERTIFICATES

ASTM Standard Textured / Perforated HDPE Geocells For Slope / Retaining Wall / Road Reinforcement 100-445mm 7
